| Machine Size
Packing Size |
Machine:3500*1700*2200mm Packing: 3600x1800x2300mm | |
| Weight | 3000KG/3100KG(wooden box) | |
| Electrical specifications | 380V，10KW | |
| Heating gun 2 PCS | 8 KW | |
| Capacity | 60-80Pcs/min | |
| Paper size | Single PE/Double PE | |
| Paper gram | 150-350g/㎡ | |
| （A)φ220mm | (B)φ215mm | |
| Cup size | (C)φ175mm | (D)φ10mm-15 |
Specification :
| Item | Qty | Brand | Remard |
| Ultrasonic | 1 | Kejian | |
| Breaker | 1 | Schneider | |
| Mini Relay | 1 | Schneider | |
| AC Contractor | 1 | Schneider | |
| Solid Relay | 1 | Taiwan FOTEK | |
| Photoelctric switch | 1 | Autonics | |
| Servo motor | 6 | Inovance | 200w-2kw |
| inverter | 1 | Inovance | |
| PLC | 1 | Inovance | including program |
| Screen | 1 | Inovance | including wires |
| Encoder | 1 | Autonics | 5 meters |
| Switch Power | 1 | Autonics |
