| Max paper size |
1080 × 780 mm |
| Min paper size |
400 × 330 mm |
| Max cutting size |
1075 × 770 mm |
| Die frame inner size |
1100 × 790 mm |
| Cutting plate size |
1080 × 780 mm |
| Min gripper edge size |
7 mm |
| Cutting precision |
≤±0.1 mm |
| Max cutting pressure |
300 T |
| Max cutting speed |
7000 S/H |
| Pre-stacking height |
1550 mm |
| Delivery stack height |
1400 mm |
| Application – White board |
0.1～2 mm |
| Application – Corrugated paper |
＜4 mm |
| Main motor power |
11 KW |
| Total power |
17.8 KW |
| Dimension (L×W×H) – SPM1080 |
4880(+1650) × 2100(+1600) × 2350 mm |
| Dimension (L×W×H) – SPM1080S |
5880(+1650) × 2100(+1600) × 2350 mm |
| Weight – SPM1080 |
14 MT |
| Weight – SPM1080S |
16 MT |
